RAIDMAX Vampire RX-900GH Continuous 900 watts ATX12V / EPS12V SLI CrossFire 80 PLUS GOLD Certified Modular PFC Power Supply Intel Haswell Platform Ready

Learn more about the Raidmax RX-900GH

Model

Brand

RAIDMAX

Model

RX-900GH

Series

Vampire

Spec

Type

ATX12V / EPS12V

Maximum Power

Continuous 900 watts

Fans

135 mm Fan

PFC

Yes

Main Connector

20+4Pin

+12V Rails

2

PCI-Express Connector

6 x 6+2-Pin

SATA Power Connector

8

SLI

SLI Ready

CrossFire

CrossFire Ready

Modular

Modular

Efficiency

up to 90.98%

Energy-Efficient

80 PLUS GOLD Certified

Over Voltage Protection

Yes

Overload Protection

Yes

Input Voltage

110 - 240 V

Input Frequency Range

50/60 Hz

Input Current

15A

Output

+3.3V@25A, +5V@25A, +12V1@50A, +12V2@50A, [email protected] ,5VSB@3A

MTBF

>100,000 Hours

Approvals

UL, CUL, TUV, FCC, CE,

Dimensions

3.50" x 6.00" x 6.50" (H x W x D)

Weight

6.80 lbs.

Features

Connectors

1x 20+4-Pin Main Connector
1x 4+4-Pin ATX12V/EPS12V Connector
6 x 6+2-Pin PCI-E Connector
8 x 5-Pin SATA Connector
6 x 4-Pin Peripheral Connector
2 x 4-Pin Floppy Connector

Features

80 Plus Gold Certified

Compatible with Latest PC Technology
- Supports the newest specifications of ATX12V
- Created for usage with current and next-generation multi-core CPU platforms
- Intel Haswell platform ready

Support Multi-GPU Technology
- Supports PCI Express 2.0 next-generation graphic card with PCI-E connector

Active Power Factor Correction (Active PFC)
- PF Value up to 99%, provides clean and reliable power

Ultra-Quiet & Temperature-Controlled fan
- Temperature-controlled design adapts its rotating speed to the PSU temperature. Even on its highest rotating level, the fan is still quiet enough to be barely noticeable

5VSB OVP design
- Provide full protection for your USB devices

Full protections with SCP, OVP, UVP and OPP.
