FEATURES
- Modularized Cable design for easy cable management and improved airflow inside the case.
- Environmental friendly technology reduces the loss of electricity and save your money on facility bill and High Efficiency.
- ATX 12V EPS12V: Supports ATX 12V2.3 version and EPS12V 2.92 version.
- Active PFC, Quad+12v Rails. Design supports all HIGH-END Multi-Core GPU graphic cards.
- Optimized Silent Design 135 MM Fan maximizes the airflow and minimizes the noise.
- PCI-E Dedicated PCI-Express VGA Connector for high performance interface VGA Card Extended Power.
- High compatibility. (3.3v, 5v, 12v, with standby design)
- Industrial grade protection circuitry Prevents damage resulting from SCP, OCP, OVP, UVP, OPP.
- 80 PLUS GOLD Certified for energy saving
SPECIFICATIONS
MODEL
|
RX-850AE
|
|
AC INPUT:
|
AC 115V-230V, 15A , 50-60HZ
|
|
DC OUTPUT:
|
+3.3V
|
+5V
|
+12V1
|
+12V2
|
+12V3
|
+12V4
|
-12V
|
+5VSB
|
|
MAX OUTPUT CURRENT:
|
24A
|
30A
|
34A
|
34A
|
34A
|
34A
|
0.5A
|
3.0A
|
|
MAX COMBINED POWER:
|
150W
|
732W
|
6W
|
15W
|
|
TOTAL POWER:
|
850W
|
CONNECTORS
|
 |
 |
 |
 |
 |
 |
 |
|
M/B 20+4 PIN
|
CPU 4+4 PIN
|
CPU 8 PIN
|
PCI-E 6+2 PIN
|
SATA
|
MOLEX 4 PIN
|
FLOPPY
|
|
x 1
|
x 1
|
x 1
|
x 4
|
x 8
|
x 8
|
x 2
|
