Fan Dimensions
120X120X25mm
|
Net Weight
816±10g
|
Fan Speed
600±200-2200±10%RPM
|
Fan Air Flow
91.12CFM(MAX)
|
|
Fan Air Pressure
3.71mmH2O(MAX)
|
Fan Life Expectancy
100000 hours
|
Fan Noise Level
17.6~39.3dB(A)
|
Fan Bearing Type
FDB（Fluid Dynamic Bearing）
|
|
Fan Connector
4Pin
|
Fan Rated Voltage
12VDC
|
Fan Rated Current
0.26±10%A(MAX)
|
Fan Power Consumption
3.12W
|
|
Main system Dimensions
70X85.6X31.5mm
|
Radiator Dimensions
154X120X27mm
|
Radiator Material
Aluminum
|
Pump Life Expectancy
120000 hours
|
|
Pump Connector
3Pin
|
Pump Operating Voltage
6~13.8VDC
|
Pump Rated Voltage
12VDC
|
Pump Speed
2200±10%RPM
|
|
Pump Current
0.16±15%A
|
Pump Power Consumption
1.92W
|
|
|
