CORSAIR CX Series CX850M CP-9020099-NA 850W ATX12V / EPS12V 80 PLUS BRONZE Certified Modular Power Supply

Learn more about the Corsair CP-9020099-NA

Model

Brand

CORSAIR

Model

CP-9020099-NA

Details

Type

ATX12V / EPS12V

Maximum Power

850W

Fans

1

Main Connector

20+4Pin

+12V Rails

Single

PCI-Express Connector

3 x 6+2-Pin

SATA Power Connector

3

Haswell Support

Ready

Modular

Modular

Efficiency

85%

Energy-Efficient

80 PLUS BRONZE Certified

Over Voltage Protection

Yes

Overload Protection

Yes

Input Voltage

100 - 240 V

Input Frequency Range

47 - 63 Hz

Input Current

12A – 6A

Output

+3.3V@25A, +5V@25A, +12V@70A, [email protected], +5VSB@3A

Features

Connectors

Motherboard cable (20+4 pin): 1
Motherboard cable length (+/- 10mm): 1x 600 mm
CPU power Cable( 4+4-pin, works as either 4 or 8-pin: 1
CPU power cable length (+/- 10mm): 1x 650 mm
PCIe 6+2 pin (GPU): 2
PCIe power cable length (+/- 10mm): 2x 750 mm
4-pin peripheral cable: 2
4-pin peripheral cable length (+/- 10mm): 2x 750 mm
SATA cable: 2
SATA cable length (+/- 10mm): 2x 800 mm
Floppy power adapter cable: 2

Features

Up to 85% energy efficiency means less heat generation and lower energy bills.

0.99 Active Power Factor Correction provides clean and reliable power.

Universal AC input from 100-240V.

A dedicated single +12V rail offers maximum compatibility with the latest components.

Over-voltage and over-power protection, under-voltage protection, and short circuit protection provide maximum
safety to your critical system components.

Extra long fully-sleeved cables support full tower chassis.

It supports the latest ATX12V v2.3 standard and is backward compatible with ATX12V 2.2 and ATX12V 2.01
systems.

ErP Lot 6 Compliant

A three year warranty and lifetime access to Corsair’s legendary technical support and customer service.
