Great-value micro-ATX H110 with 5X Protection II for dependable stability, DDR4 support, and UEFI BIOS with EZ Flash 3

• 5X Protection II – Advanced hardware safeguards for all-round protection
• DDR4 memory support
• Media-acclaimed UEFI BIOS with EZ Flash 3
• Easy PC DIY with safe motherboard-mounting design
• Fan Xpert dedicated CPU and case fan controls for ultimate cooling and silent performance

• CPU Intel® for 6^th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
  Supports Intel® 14 nm CPU
  Supports Intel® Turbo Boost Technology 2.0
  * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for CPU support list
• Chipset Intel® H110
• Memory2 x DIMM, Max. 32GB, DDR4 2133 MHz Non-ECC, Un-buffered Memory
  Supports Intel® Extreme Memory Profile (XMP)
  * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
• GraphicIntegrated Graphics Processor- Intel® HD Graphics support
  Multi-VGA output support : DVI-D/RGB ports
  - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
  - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB
  Supports Intel® Quick Sync Video, Clear Video HD Technology
• Expansion Slots1 x PCIe 3.0/2.0 x1 (x16 mode)
  2 x PCIe 2.0 x1
  1 x PCI
• StorageIntel® H110 chipset :
  4 x SATA 6Gb/s port(s), gray,
• LANRealtek® RTL8111H, 1 x Gigabit LAN Controller(s)
• AudioRealtek® ALC887 8-Channel High Definition Audio CODEC *¹
  - Supports : Jack-detection, Front Panel Jack-retasking
• USB PortsIntel® H110 chipset :
  4 x USB 3.0/2.0 port(s) (2 at bac
